4-Digit Combination Lock - Extending Bar Lock
4‑digit combination extending bar lock
DL‑708 zinc alloy lock
keyless extending rod lock
Panel Dial lock 18–23 mm
Heavy‑duty combination lock
DL‑708 zinc alloy lock
keyless extending rod lock
Panel Dial lock 18–23 mm
Heavy‑duty combination lock
Model :
DL-708
- Material: Zinc Alloy
- Finish: Matte Chrome. Other finish is available by special request.
- Door thickness: 18~23mm
Combination Lock - Extending Bar Lock Type
● For thickness 18mm-23mm
● Horizontal or Vertical model available for your selection
ITEM NO.: DL-708
|
POSITION |
THICKNESS |
ORDER NO. FOR LOCK BODY ONLY |
FINISH |
|
|
LEFT |
RIGHT |
|||
|
HORIZONTAL |
18 - 23mm |
DL-MC708L |
DL-MC708R |
MATTE CHROME |
|
VERTICAL |
DL-MC708VL |
DL-MC708VR |
||
Material: ZINC ALLOY
Key profile: 4F
Accessories:
1 Cam
2 L type striking plate (A0007(DS-02-8N))
- Door compatibility: Designed for panel thickness from 18 to 23 mm
- Combination code: 4‑digit mechanism—10,000 possibilities for secure, keyless access
- Configurations: Available in both horizontal and vertical mounting options
- Accessories included: Extending bar, strike plate (type 2 L, A0007/DS‑02‑8N)
- Metal cabinets and filing systems
- Display cases or exhibition furniture
- Utility panels and access enclosures
- Office or industrial lockers
